2.5T/6m Diesel Genie Telehandler

A small footprint with real lifting power is what the Genie GTH-2506 telehandler offers: a 2,500kg lift capacity and 5.79m lift height packed into a chassis compact enough for sites where a standard telehandler just won't fit. Three steering modes (front wheel, crab and coordinated) mean operators can work through tight access points without the usual three-point-turn routine, and a limited slip diff keeps drive planted when the ground gets rough. Forward reach tops out at 3.3m, plenty for loading, unloading and placement work across a busy site. The Load Management System is a dynamic colour-coded load chart on a 7" display, paired with a reversing camera, so operators always know exactly where they stand before they lift. Available for hire from Skyreach - get in touch to book telehandler rental for your next project.

Help Me Choose

Lifting height maximum 5.79 m 19 ft

Lifting capacity maximum 2,500 kg 5,511 lbs

Lift capacity at maximum height 2,000 kg 4,409 lbs

Lift capacity at maximum reach 900 kg 1,984 lbs

Forward reach maximum 3.33 m 10 ft 11 in

Reach at maximum height 60 cm 2 ft

Height 2.16 m 7 ft 1 in

Height at steering wheel 1.25 m 4 ft 1 in

Width 1.81 m 5 ft 11 in

Cab width 86 cm 2 ft 10 in

Track 1.5 m 4 ft 11 in

Wheelbase 2.36 m 7 ft 9 in

Length at front wheels 3.35 m 11 ft

Length at fork-holder plate 3.84 m 12 ft 7 in

Ground clearance 33 cm 1 ft 1 in

Overall length 5.04 m 16 ft 6.5 in

Obstruction angle 90°

Departure angle 60°

Inside/outside turning radius 1.6 m/4 m 5 ft 3 in/13 ft 1 in

Break-out force 3,700 kg 8,157 lbs

Towing capacity at dynamometer 3,100 kg 6,834 lbs

Drive speed max. 23 km/h 14 mph

Fork-holder plate rotation 130°

Tyres (DIN 70361) 12-16.5” PR10 8 hole wheel rim

Lifting/lowering speed 8 sec./7.5 sec.

Extension/retraction speed 8 sec./6 sec.

Engine Deutz TD 2.9 L4, 4-cylinder diesel 74 hp (55.4 kW), stage IIIA

Transmission Hydrostatic variable displacement pump linked to variable displacement motor. Both piston type.

Function pump Boom & Control system gear pump type: 280 Bar, 70 L/min.

Fuel tank capacity 60 L 15.9 gal

Engine oil capacity 10 L 2.6 gal

Hydraulic oil tank capacity 65 L 17.2 gal

Weight 5,420 kg 11,948 lbs

Operators Licence Contact Us

Features

4WD
Rough terrain
