53ft (16.15m) Diesel Genie Scissor Lift

Diesel 53ft (16.15m) Genie Scissor Lift has 4WD accessibility, it is suitable for outdoor and rough terrain use, and has a gradeability of 40%. Supplying safety at a working height of 18.15m for a team of up to 4 people, this Scissor Lift is available to hire from Skyreach.

Help Me Choose

Working height maximum 18.15 m 59 ft

Platform height maximum 16.15 m 53 ft

Platform height - stowed 2.02 m 6 ft 7.5 in

Platform length 3.98 m 13 ft 0.5 in

Platform length: outside, extended 6.57 m 21 ft 6.5 in

Slide-out platform extension deck - front 1.52 m 5 ft

Slide-out platform extension deck - rear 1.22 m 4 ft

Platform width - outside 1.83 m 6 ft

Height: stowed 3.15 m 10 ft 4 in

Height: stowed - rails lowered 2.47 m 8 ft 1.25 in

Length - stowed 4.88 m 16 ft

Length - extended 6.57 m 21 ft 6.5 in

Width 2.34 m 7 ft 8 in

Wheelbase 2.84 m 9 ft 4 in

Ground clearance - center 0.36 m 1 ft 2 in

Maximum platform occupancy 4

Lift capacity 680 kg 1,500 lbs

Lift capacity - extension deck 227 kg 500 lbs

Drive height 9.14 m 30 ft

Drive speed - stowed 6.4 km/h 4.0 mph

Drive speed - raised 1.1 km/h 0.7 mph

Gradeability - stowed 40%

Maximum outrigger leveling: front to back 7°

Maximum outrigger leveling: side to side 12°

Turning radius - inside 2.16 m 7 ft 1 in

Turning radius - outside 5.33 m 17 ft 6 in

Controls proportional

Drive four wheel

Raise / lower speed 55 / 49 sec

Tires - foam-filled rough terrain 30 x 84 cm 12 x 33 in

Power source Deutz D2011L03i 3 cylinder diesel 48 hp (35.8 kW)

Auxiliary power unit 12 V DC

Fuel tank capacity 113.6 L 30 gal

Hydraulic system capacity 113.6 L 30 gal

Weight 7,776 kg 17,142 lbs

Standards Compliance AS 1418.10

Operators Licence Duty of Care Operator Training (e.g. EWPA Yellow Card)

Features

4WD
Foam-filled tyres
Non-marking tyres
Rough terrain
